Rigging hoist ring lifting eye bolts swivel eye

Rigging hoist ring lifting eye bolts swivel eye
Rigging hoist ring lifting eye bolts swivel eye
Product Code : B003
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
Product Specifications
  • Condition
  • New
  • Usage
  • Lifting equipment
  • Power Source
  • Manual
  • Feature
  • 360 degree rotation with 90 degree pivot function.
  • Warranty
  • half year
Product Description

Rigging hoist ring lifting eye bolts swivel eye



Quick Detail:OTEHR NAME

Long Bolt Swivel Hoist Ring

Swivel Point Long Bolt

Attachment Swivel/lifting points

Swivel Eye Bolts

Lifting Eyes

Key Eye Point

Weld to on Lifting Point

Swivel point link/forged hoist rings

Description:

Name

Forged Hoist Rings/Lifting Points

WLL

0.3tons to 60tons

Material

Forged super alloy steel to Quenched Tempered

Load Testing

Individually proof test at 2.5 times Working Load Limit

Fatigue Tested

Fatigue tested at 1.5 times Working Load Limit for 2000 cycles

Breakage Test

Breakage test magnaflux crack detection

Function

With spring inside for better pivoting control

Feature

Rated at 100% at  any angle



Applications:

Yiyun hoist rings are trusted and used every day when loads are required to be lifted with high quality hoist rings. As the leading manufacturer of hoist rings and safety lifting devices in China, many of sectors of the economy trust and apply our products such as:Aerospace,Defense,Manufacturing,Stamping and Injection Molding,Power Generation (nuclear, hydro, wind),Construction,Mining,Concrete and Precast.Towers...



Specifications:

Forged Swivel Hoist Rings/Lifting Points

Code

Hoist Rings Category

Thread Size(mm)

WLL Range( tons)

Icon

YDS

Universal Swivel Shackle

M8 to M100

0.5 to 32



YD081

Side Pull/Side Load

M8 to M56

0.3 to 22



YD082

Heavy Load Side

M56 to M125

22 to 50



YD083

Bolt to on Attachment Swivel

M6 to M100

0.3 to 50



YD084

Swivel Eye bolts

M8 to M48

0.3 to 12



1.)Bolts length available to meet specific application requirement

2.)All dimensions approximate  variations do not effect use or design factor.



Competitive Advantage:

Compact and light in design&structure;

Swivels may changed on all sides,turning 360

Link s rotation radius max.180

Secured four times against breakage in all load directions;

Able  to  rotation under load;

Trade Information
  • FOB Port
  • tianjin
  • Payment Terms
  • Western Union, Telegraphic Transfer (T/T), Cheque
  • Supply Ability
  • 1299 Per Day
  • Delivery Time
  • 7 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Free samples are available
  • Packaging Details
  • Outer carton with inner packing: PP bag or rubble bag with soft material.
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Certifications
  • CE &SGS
